Vet Vital Signs Monitor VE5

The BLUEJUNTAGS VE5 is a compact, portable veterinary vital signs monitor for pulse rate, blood oxygen saturation and non-invasive blood pressure. It is designed for use during surgery, in post-anaesthetic recovery and for spot checks in consulting rooms.

Technical specification

• SpO2 measuring range: 0-100%, resolution 1%. Accuracy — medium: 70-100% ±2%, 0-69% undefined; small: 70-100% ±3%, 0-69% undefined
• PR measuring range: 30-255bpm, resolution 1bpm, accuracy ±3bpm, refresh time 1s
• NIBP measuring range: systolic 40-270mmHg, diastolic 10-210mmHg, average pressure 20-230mmHg
• Static pressure range: 0-300mmHg (0-40kPa)
• Anti-electric shock type: Class I with internal power supply
• Anti-electric shock degree: CF-type application part
• Protection degree of fluid intake: IPX1
• Operate mode: continuous work
• Input: AC100V-240V, 50/60Hz, maximum input power 70VA
• Output: 12V 2A; fuse specification 2AL 16V
• Internal lithium battery: DC 7.4V, not less than 2000mAh

Key features

• Compact and portable, supplied with a carrying handle
• Audible and visual alarm — auto double alarm with audible and visible signals
• Three audible alarm modes corresponding to the alarm state
• Trend review: short trend 1 hour at 1s or 5s resolution; long trend 96 hours at 1, 5 or 10 minute resolution
• NIBP measurement review of data from 400 NIBP measurements
• Indicator lights for alarm (yellow/red), working status (green) and battery charging (green)
• Built-in lithium battery and charging socket support multiple charging methods

Applications

Intra-operative monitoring, anaesthesia recovery and rapid assessment of cats, dogs and larger animals.

Wholesale, OEM and export

Supplied wholesale to pet hospitals, veterinary clinics and medical device distributors, with OEM/ODM support and export documentation available on request.
